INDUSTRIAL AIR COOLER

CorTec Evaporative Industrial air cooler is a natural and highly efficient cooling method that uses the physical process of water evaporation to effectively absorb heat. The technology stands out for its outstanding efficiency and environmentally characteristics.

TECHNICAL PARAMETER

Mobile Air Cooler Air Volume (m³/H) Power Voltage Water Consumption (L/H) Water Tank Dimension Net Weight Cover Area
CTEAC-1100-Single
18000 1.1KW 220V/380V 20L 200L 1110*1110*1880 mm 65KG 120m²
CTEAC-1100-Double
18000 1.1KW 220V/380V 20L 200L 1110*1110*1850 mm 65KG 120m²
CTEAC-1100-Four
18000 1.1KW 220V/380V 20L 200L 1110*1110*1580 mm 65KG 120m²
CTEAC-1500-Single
22000 1.5KW 220V/380V 20L 200L 1110*1110*1880 mm 70KG 150m²
CTEAC-1500-Double
22000 1.5KW 220V/380V 20L 200L 1110*1110*1850 mm 70KG 150m²
CTEAC-1500-Four
22000 1.5KW 220V/380V 20L 200L 1110*1110*1580 mm 70KG 150m²
CTEAC-2200-Single
25000 2.2KW 220V/380V 30L 200L 1110*1110*2080 mm 75KG 200m²
CTEAC-2200-Double
25000 2.2KW 220V/380V 30L 200L 1110*1110*2030 mm 75KG 200m²
CTEAC-2200-Four/ Eight
25000 2.2KW 220V/380V 30L 200L 1110*1110*1585 mm 75KG 200m²

Wall Air Cooler Air Volume (m³/H) Power Voltage Water Consumption (L/H) Water Tank Dimension Net Weight Cover Area
CTEAC-1100-Up/ Down/ Side
18000 1.1KW 220V/380V 5-10L 20L 1100*1100*940 mm 54KG 100-150m²
CTEAC-1500-Up/ Down/ Side
22000 1.5KW 220V/380V 5-10L 20L 1100*1100*940 mm 58KG 150-180m²
CTEAC-2200-Up/ Down/ Side
25000 2.2KW 220V/380V 10-20L 20L 1110*1110*1150 mm 65KG 180-220m²
CTEAC-3000-Up/ Down
35000 3KW 220V/380V 20-30L 30L 1350*1350*1250 mm 80KG 200-260m²
CTEAC-4000-Up
40000 4KW 220V/380V 30-35L 45L 1500*1500*1450 mm 110KG 400-500m²

PRODUCT DESCRIPTION



Fan Motor

High speed pure copper core motor, water-proof motor with long lifetime, better balance and stability, RPM is 1450 which high speed motor.

Body Case.

100% New PPmaterial, not recyelable, anti-UV, anti-corrosion, anti-aging, better heat-resistant performance:<60'C, 8 years warranty, more than l2 years lifetime.



Fan Blades

Aluminium casting fan blades which is not easy to deform or break under heavy pressure. Its with large air volume, low noise and very stable.



WATER PUMP

Ceramic shaft submersible pump, Corrosion resistance and efficient performance, 30000hours continuously working life.



Water Curtain

Thickened water curtain make cooling speed faster, when working there is no water spatter, its not easy to deform, and long lifetime


CorTec Evaporative Air Cooler Ideal Applications

Workshops/Factories: Cooling production lines, assembly areas, machinery halls. Reduces heat stress, improves worker comfort/productivity, and combats dust.
Farms/Livestock Buildings: Critical for cooling poultry, dairy cows, pigs, etc., preventing heat stress, improving health/growth, and reducing mortality. Also useful in milking parlors and processing areas.
Warehouses & Distribution Centers:Provides cost-effective cooling and ventilation in large, high-ceiling spaces with heat build-up.
Greenhouses: Provides essential cooling and humidity control for optimal plant growth using fresh air, often more economically than other methods.
Bus/Train Stations & Waiting Areas: Offers affordable cooling and fresh air exchange in large, often semi-open public spaces.
Markets (Covered/Open-Air) & Event Tents: Provide cooling and ventilation for vendors and shoppers in expansive areas.
Gymnasiums & Sports Halls: Efficiently manages heat and humidity from activity.
Restaurants (Kitchens/Patios) & Workshops: Spot cooling for heat-intensive areas.


In Summary:
CorTec Evaporative industrial evaporative air cooler is a highly energy-efficient, cost-effective solution for cooling, humidifying (in dry air), and purifying large volumes of air in demanding industrial, agricultural, and commercial spaces. Its low noise operation (mute effect) and fresh air delivery make it particularly well-suited for the hot, dry periods common in many regions where the listed applications (workshops, farms, warehouses, etc.) operate. It excels where high airflow, dust control, low operating costs, and worker/animal comfort are priorities, provided the ambient humidity levels are compatible.
